FEATURES
Working Pressure:1/4″~4″1000WOG
Reduced Port
Blow out-Proof Stem Design
Locking Device
Available Investment Casting
Working Temperature:-20°C ~150°C
Suitable Medium:Water,Oil,Gas
FEATURES
Working Pressure:1/4″~4″1000WOG
Reduced Port
Blow out-Proof Stem Design
Locking Device
Available Investment Casting
Working Temperature:-20°C ~150°C
Suitable Medium:Water,Oil,Gas
STANDARDS
Design Standard:ASME B16.34
Threaded Ends:ANSI B.20.1(NPT):BS21;DIN2999/259;1S0228/1;ISO7/1
Inspection and testing:API598/MSS SP-110/EN 12266
| Parts Name | Material |
|---|---|
| Body | CF8/CF8M |
| Cap | CF8/CF8M |
| Ball | SS304/SS316 |
| Stem | SS304/SS316 |
| Seat | PTFE |
| Cap Seal | PTFE |
| T. Washer | PTFE |
| Gland | SS304 |
| S. Washer | SS304 |
| Nut | SS304 |
| Handle | SS201/SS304 |
| Handle Cover | PVC |
