FEATURES
Working Pressure:1/4″~4″1000WOG
Blow out-Proof Stem Design
ISO5211 Direct Mounting Pad
Installable actuator
Available Investment Casting
Working Temperature:-20°C ~150°C
Suitable Medium:Water,Oil,Gas
FEATURES
Working Pressure:1/4″~4″1000WOG
Blow out-Proof Stem Design
ISO5211 Direct Mounting Pad
Installable actuator
Available Investment Casting
Working Temperature:-20°C ~150°C
Suitable Medium:Water,Oil,Gas
STANDARDS
Design Standard:ASME B16.34
Threaded Ends:ANSI B.20.1(NPT):BS21;DIN2999/259;1S0228/1;ISO7/1
Inspection and testing:API598/MSS SP-110/EN 12266
| PART NAME | MATERIAL | ||
|---|---|---|---|
| BODY | CF8M | CF8 | WCB |
| SEAT | PTFE | PTFE | PTFE |
| BALL | SS316 | SS304 | SS304 |
| WASHER | SS316 | SS304 | SS304 |
| INSERT | SS316 | SS304 | SS304 |
| THRUST WASHER | PTFE | PTFE | PTFE |
| STEM | SS316 | SS304 | SS304 |
| STEM PACKING | PTFE | PTFE | PTFE |
| GLAND | SS304 | SS304 | SS304 |
| NUT | SS304 | SS304 | SS304 |
| LOCKING | SS201 | SS201 | SS201 |
| HANDLE | SS201 | SS201 | SS210 |
| HANDLE COVER | PVC | PVC | PVC |
