FEATURES
Working Pressure:1/4″~4″1000WOG
Blow out-Proof Stem Design
Available Investment Casting
Working Temperature:-20°C ~150°C
Suitable Medium:Water,Oil,Gas
FEATURES
Working Pressure:1/4″~4″1000WOG
Blow out-Proof Stem Design
Available Investment Casting
Working Temperature:-20°C ~150°C
Suitable Medium:Water,Oil,Gas
STANDARDS
Design Standard:ASME B16.34
Threaded Ends:ANSI B.20.1(NPT):BS21;DIN2999/259;1S0228/1;ISO7/1
Inspection and testing:API598/MSS SP-110/EN 12266
| 1 | Cap | CF8M/CF8/WCB | 9 | Thrust Washer | PTFE |
| 2 | Bolt Washer | SS304/SS/SS316 | 10 | Packing | PTFE |
| 3 | Hex Nut | SS304/SS/SS316 | 11 | Gland | SS304/SS |
| 4 | Bolt | SS304/SS/SS316 | 12 | Handle | SS304/SS |
| 5 | Body | CF8M/CF8/WCB | 13 | Spring Washer | SS304/SS |
| 6 | Seat | PTFE | 14 | Stem Nut | SS304/SS |
| 7 | Ball | SS316/SS304/SS | 15 | Plastic Cover | Plastic |
| 8 | Stem | SS316/SS304/SS |
