FEATURES
Working Pressure:1/2″~4″ 200WOG
Full Port
SS Integrated Seat
Operation:Hand Wheel
Various Thread Standards Available
Investment Casting
Working Temperature:-20°C~245°C
Suitable Medium:Water,Oil,Gas
FEATURES
Working Pressure:1/2″~4″ 200WOG
Full Port
SS Integrated Seat
Operation:Hand Wheel
Various Thread Standards Available
Investment Casting
Working Temperature:-20°C~245°C
Suitable Medium:Water,Oil,Gas
STANDARDS
Design Standard:ASME B16.34
Threaded Ends:ANSI B.20.1(NPT):BS21:DIN2999/259;1S0228/1;ISB03;ISO7/1
Inspection and testing:AP1598/MSS SP-110/EN 12266
| PART NAME | MATERIAL | |
|---|---|---|
| BODY | CF8M | CF8 |
| WEDGE | CF8M | CF8 |
| STEM | SS316 | SS304 |
| CAP | CF8M | CF8 |
| JOINT GASKET | PTFE | PTFE |
| SNAPRING | SS304 | SS304 |
| THRUST WASHER | SS304 | SS304 |
| PACKING | PTFE | PTFE |
| GLAND BUSH | 304 | SS304 |
| CAP NUT | CF8M | CF8 |
| HAND WHEEL | QT400-18 | QT400-18 |
| Spring washer | SS304 | SS304 |
| NUT | SS304 | SS304 |
