Feature
Working Pressure:2″~20″
Working Pressure: PN16 PN40
Working Temperature: -20ºC~180ºC
Applicable Medium: Water,Oil,Gas,Acid
Feature
Working Pressure:2″~20″
Working Pressure: PN16 PN40
Working Temperature: -20ºC~180ºC
Applicable Medium: Water,Oil,Gas,Acid
| PART NAME | MATERIAL | ||
|---|---|---|---|
| BODY | Stainless Steel | CF8 | CF8M |
| BONNET | Stainless Steel | CF8 | CF8M |
| DISC | SUS304,SUS316 | CF8 | CF8M |
| SIZE | DN50~DN300 | ||
| PRESSURE RANGE | PN10，PN16.PN25，PN40 | ||
| DESIGN STANDARD | DIN | ||
| FACE TO FACE | DIN | ||
| FLANGE STANDARD | DIN | ||
| TESTING STANDARD | API598 | ||
