STANDARDS
Design Standard:ASME B16.34
Threaded Ends:ANSI B.20.1(NPT):BS21:DIN2999/259;1S0228/1;ISB03;ISO7/1
Inspection and testing:AP1598/MSS SP-110/EN 12266
FEATURES
Working Pressure:1/2″~2″
Working Pressure: 800WOG
Working Temperature: -20ºC~180ºC
Applicable Medium: Water,Oil,Gas
Design Standard: ASME B16.34
Wall Thickness: ASME B16.34
Thread Standard: ASME B1.20.1. BS21
Inspection and testing: MSS SP-110/EN 12266
STANDARDS
Design Standard:ASME B16.34
Threaded Ends:ANSI B.20.1(NPT):BS21:DIN2999/259;1S0228/1;ISB03;ISO7/1
Inspection and testing:AP1598/MSS SP-110/EN 12266
| PART NAME | MATERIAL | |
|---|---|---|
| BODY | CF8M | CF8 |
| DISC | SS316 | SS304 |
| CAP | CF8M | CF8 |
| JOINT GASKET | PTFE | PTFE |
| PIN | SS304 | SS304 |
| GASKET | PTFE | PTFE |
| BOIT | SS304 | SS304 |
