FEATURES
Working Pressure:1/2″~3″ 200WOG
Full Port
SS Integrated Seat
Various Thread Standards Available
Investment Casting
Working Temperature:-20°C~180°C
Suitable Medium:Water,Oil,Gas
FEATURES
Working Pressure:1/2″~3″ 200WOG
Full Port
SS Integrated Seat
Various Thread Standards Available
Investment Casting
Working Temperature:-20°C~180°C
Suitable Medium:Water,Oil,Gas
STANDARDS
Design Standard:ASME B16.34
Threaded Ends:ANSI B.20.1(NPT):BS21:DIN2999/259;1S0228/1;ISB03;ISO7/1
Inspection and testing:AP1598/MSS SP-110/EN 12266
| PART NAME | MATERIAL | |
|---|---|---|
| BODY | CF8M | CF8 |
| WASHER | SS316 | SS304 |
| SEAT | PTFE | PTFE |
| BOIT | SS304 | SS304 |
| DISC | CF8M | CF8 |
| SPRING | SS316 | SS304 |
| CAP | CF8M | CF8 |
| JOINT GASKET | PTFE | PTFE |
